Most electrical work SWMS documents on Australian sites rest on a single word: de-energised. The document asserts it. Nobody proves it. Meanwhile the switchboard sits three rooms away, unlocked, under someone else’s control.
That gap is where people die. A document that names an outcome without naming the person, the lock, the tester and the test does not control anything. It records an intention and hopes.
So this post walks the isolation chain the WHS Regulations actually require, from the de-energised default to the four narrow gates that permit live work.
What the WHS Act requires of an electrical work SWMS
Section 19 of the WHS Act 2011 requires a PCBU to provide safe systems of work. Section 27 requires officers to verify that those systems exist and work. For electricity, the Regulations then set out exactly what safe looks like.
Work carried out on or near energised electrical installations or services is high risk construction work under Regulation 291(k). Therefore Regulation 299 requires a SWMS before the work starts. Regulation 147 sits alongside it and requires the PCBU to eliminate electrical risks, or to minimise them so far as is reasonably practicable.
However, the SWMS is only the entry ticket. Part 4.7 of the Regulations governs the work itself, and it is far more specific than most site documents assume. Regulations 154 to 165 name the duty, the duty holder and the proof.
So an electrical work SWMS earns its keep by describing that chain in order. It names who isolates, who locks, who tests, who watches and who restores supply.
De-energised is the default, not the preference
Regulation 154 prohibits electrical work on energised electrical equipment. The prohibition comes first, and the exceptions come later. That order matters, because it puts the burden on the crew to justify live work rather than to justify isolation.
Most site documents get this backwards. They describe isolation as a preference, then quietly leave room for the sparky to make a call at the board. Instead, a compliant electrical work SWMS starts from that hard default and treats the four departures as exceptions to justify.
Regulation 156 protects that default once it is in place. De-energised equipment must not be inadvertently re-energised while the work runs. A single line reading isolate supply does not achieve that. Neither does a switch someone flicked off and walked away from.
Test before touch: the electrical work SWMS duty most crews skip
Regulation 155 is the duty most electrical documents skip. Before anyone works on electrical equipment, a competent person must test that equipment to determine whether or not it is energised. Treat every exposed part as energised until someone isolates it and proves otherwise, and earth every high voltage exposed part after de-energising.
The model Code of Practice Managing electrical risks in the workplace turns that duty into a sequence. Prove the tester on a known live source. Test the equipment at the work face. Then prove the tester again on the known live source, so a failed instrument cannot pass as a dead circuit.
Notably, the Code also rules out shortcuts. Panel voltmeters never stand as the only proof that a part sits de-energised. Testing happens each time before work starts, and again whenever the worker leaves the immediate area and returns.
An electrical work SWMS should name the test instrument, the known live source and the person who holds both.
Isolation is a physical act with a named owner
The Code is blunt about ownership. The point of isolation should be under the control of the person carrying out the work on the isolated conductors. Control means a lock in their hand, not a phone call to the switch room.
In practice the crew locks off circuit breakers, switches and combined fuse switch units wherever possible. Where locking proves impractical, they remove the conductors and tie them back. Danger tags then carry the names of the people the isolation protects, and only those signatories remove them.
Even so, a tag by itself performs nothing. It is information, not isolation. Out-of-service tags flag faulty equipment; danger tags protect people; neither substitutes for a lock and a proven test.
Cables deserve their own line in the electrical work SWMS. Both ends get checked for isolation before anyone cuts, because a cable fed from a second source will happily kill someone who only checked one end.
When live electrical work is actually permitted
Regulation 157 sets four gates. Live work passes only where health and safety demand it, where the equipment must stay energised for the work to proceed properly, where the testing under Regulation 155 requires it, or where no reasonable alternative exists.
Commercial pressure does not appear on that list. Neither does a tenant who wants the power on, nor a program that slipped. Consequently, where convenience is the only reason for live work, the gate stays shut.
Where a gate genuinely opens, Regulation 158 sets the preliminary steps. A competent person conducts a risk assessment for the proposed work and records it. Regulation 162 then requires the crew to keep that record for at least 28 days after the work finishes.
The safety observer and the method for energised work
Regulation 161 governs the method. Energised work runs in accordance with a safe work method statement prepared for that work, with a safety observer present. The observer must hold the competence to implement control measures in an emergency and to rescue and resuscitate the worker, with a competency assessment inside the previous 12 months.
One exception applies. A safety observer is not required where the work consists only of testing and the risk assessment shows no serious risk. Outside that narrow case, the observer stands up.
Moreover, the Code sets limits on the role. The observer carries no other task that compromises it, never stands in the work basket of the elevating work platform the electrical work runs from, and stays close enough to communicate quickly and effectively.
Regulations 159 and 160 close the perimeter. Barriers and signage keep unauthorised people out of the work area, and the crew stops anyone at the workplace from inadvertently contacting an exposed energised component.
Construction sites carry extra electrical duties
Construction work adds a layer. Regulation 163 requires compliance with AS/NZS 3012, the standard for electrical installations on construction and demolition sites, currently the 2019 edition. Site distribution boards, leads and generators all sit inside its scope.
Regulation 164 then requires residual current device protection for plug-in equipment in hostile operating environments. For socket outlets not exceeding 20 amps, the tripping current must not exceed 30 milliamps. Regulation 165 requires a competent person to test those devices regularly and to keep the records.
Alongside that, Regulation 149 requires the PCBU to disconnect or isolate unsafe electrical equipment, and Regulation 150 requires a competent person to inspect and test equipment regularly and record the results. A tagged lead is evidence. A lead with a faded tag is a finding.
Re-energisation is the gate the electrical work SWMS forgets
Restoring power deserves the same discipline as removing it. Before the first lock comes off, the crew confirms the work has finished, the covers and barriers sit back in place, the tools sit clear of the equipment and nobody remains exposed.
Then each worker removes their own lock and their own tag. Nobody cuts a colleague’s lock to get the job away on time. Where work stays unfinished overnight, the isolation stays secured and the tags stay on, so the next shift inherits a controlled state rather than a guess.
Finally, someone tests the restored supply and records the result. A checklist that stops at the last task, rather than at the restored and verified supply, leaves the most dangerous moment of the job undocumented.
Practical Application
Picture a switchboard upgrade in an occupied office fit-out. The main board sits in a services cupboard on the ground floor, the work runs on level three, and the building manager wants the lifts back by nine.
Their electrical work SWMS starts at the top of the checklist. First the crew identifies and photographs the isolation point. Both electricians and the apprentice then fit personal locks to the same hasp, and each signs the danger tag. Notably, the building manager holds a key to nothing.
Next comes the proof. S. Wilson proves the tester on the known live source at the adjacent board, tests the circuit dead at the work face, then proves the tester again. The result and the time go straight onto the checklist. After lunch, the retest on return is a line item rather than a memory.
Midway through, the building manager asks for one circuit to stay live so a tenant’s server keeps running. The team runs that request through Regulation 157 rather than through the program. That circuit does not need to stay energised for the work to proceed properly, and an after-hours window exists, so no gate opens. Work waits until seven that evening.
Three months later, the head contractor audits the job and one workbook answers everything: the isolation point, the lock owners, the tester serial number, the two proving tests, the retest after lunch, the declined live work request and its reason, and the re-energisation that the first lock owner signed off at 21:40.
Conclusion
Electricity punishes documents that describe outcomes instead of actions. A strong electrical work SWMS names the isolation point, the lock owner, the tester, the proving source, the observer and the person who restores supply. Each of those leaves evidence behind.
In other words, de-energised is a proven state, not a claim on a page. Prove it, record it, and the audit takes minutes rather than a morning.
